OSRAM XBO 4000W/DHP OFR Xenon Cinema Lamp for Barco, 170000 lm, DC 34V 123A, LCL 123mm - 69481
3 In Stock! Same Day Shipping Through 3PM CST! Need more? Call today @ 888.391.5596- Important Specs
- 4000 Watts
OSRAM XBO 4000W/DHP OFR Xenon Cinema Lamp (69481)
4000W DC xenon short-arc lamp for select Barco digital cinema projectors
High-output 4kW XBO lamp delivering 170,000 lm with 123mm LCL for proper cinema projector alignment.
High Brightness Output
170,000 lm nominal luminous flux for demanding cinema projection.
170,000 lm nominal luminous flux for demanding cinema projection.
Stable DC Electrical Profile
4000W, 34V, 123A nominal with 91–130A current control range.
4000W, 34V, 123A nominal with 91–130A current control range.
Correct Optical Geometry
123.0 mm LCL and 6.0 mm electrode gap (cold) for proper positioning.
123.0 mm LCL and 6.0 mm electrode gap (cold) for proper positioning.
Booth-Ready Operation
Forced cooling and s15/p15 burning position (vertical: anode (+) on top).
Forced cooling and s15/p15 burning position (vertical: anode (+) on top).
Fitment Details Included
SFaX27-14x80 / SFc27-16/55 bases, 60 mm diameter, connector present.
SFaX27-14x80 / SFc27-16/55 bases, 60 mm diameter, connector present.
| Specifications | |
|---|---|
| Brand / Family | OSRAM XBO |
| Product Number (Americas) | 69481 |
| Product Name (Americas) | XBO 4000W/DHP 1/CS 1/SKU |
| Global Order Reference | XBO 4000 W/DHP OFR |
| Nominal Wattage | 4000 W |
| Nominal Voltage | 34 V |
| Nominal Current | 123 A |
| Current Control Range | 91–130 A |
| Type of Current | DC |
| Nominal Luminous Flux | 170,000 lm |
| Light Center Length (LCL) | 123.0 mm |
| Electrode Gap (cold) | 6.0 mm |
| Base (Anode) | SFaX27-14x80 |
| Base (Cathode) | SFc27-16/55 |
| Diameter | 60.0 mm (2.165 in) |
| Length | 345.0 mm |
| Length w/ base excl. pins/connection | 295.0 mm |
| Cable/Wire Length (input side) | 130 mm |
| Connector Present | Yes |
| Product Weight | 670 g |
| Burning Position | s15/p15 |
| Cooling | Forced |
| Max Ambient Temp (pinch point) | 230 °C |
| Nominal Lifetime | 1100 hr |
| Warranty Hours | 1100 hrs |
| Service Warranty Lifetime | 1400 hr |
| REACh Primary Article Identifier | 10046135694810 | 4052899287792 | 4052899195790 | 4008321546272 | 4062172030397 | 4052899096080 | 4052899091825 | 4052899317208 |
Compatible Barco Projectors (per provided list)
- Barco DP2K-15C
- Barco DP2K-19B
- Barco DP2K-20C
- Barco DP2K-23B
- Barco DP4K-19B
- Barco DP4K-23B
- Barco Digital Cinema 90
- Barco Digital Cinema 100
- Barco Digital Cinema 2000
- Barco Digital Cinema 3000
Box Contents
- 1 × OSRAM XBO 4000W/DHP OFR Xenon Cinema Lamp (69481)
