OSRAM XBO 2000W/DHP L OFR Xenon Cinema Lamp for Barco, DC 23V 87A, LCL 123mm, 3300h - 68884
5 In Stock! Same Day Shipping Through 3PM CST! Need more? Call today @ 888.391.5596- Important Specs
- 2000 Watts
OSRAM XBO 2000W/DHP L OFR Xenon Cinema Lamp (68884)
2000W DC xenon short-arc lamp for select Barco digital cinema projectors
Long-life 2000W XBO xenon lamp with stable DC operation and 123mm LCL for proper cinema projector alignment.
Extended Service Life
3300 hr nominal lifetime with 3300 warranty hours (service warranty lifetime 3500 hr).
3300 hr nominal lifetime with 3300 warranty hours (service warranty lifetime 3500 hr).
Stable DC Electrical Profile
2000W, 23V, 87A nominal with 64–95A current control range.
2000W, 23V, 87A nominal with 64–95A current control range.
Correct Optical Geometry
123.0 mm LCL and 4.5 mm electrode gap (cold) for proper positioning.
123.0 mm LCL and 4.5 mm electrode gap (cold) for proper positioning.
Booth-Ready Operation
Forced cooling and s15/p15 burning position (vertical: anode (+) on top).
Forced cooling and s15/p15 burning position (vertical: anode (+) on top).
Fitment Details Included
SFaX30-14 / SFc30-16 bases, 55 mm diameter, 345 mm length, connector present.
SFaX30-14 / SFc30-16 bases, 55 mm diameter, 345 mm length, connector present.
| Specifications | |
|---|---|
| Brand / Family | OSRAM XBO |
| Product Number (Americas) | 68884 |
| Product Name (Americas) | XBO 2000W/DHP L 1/CS 1/SKU |
| Global Order Reference | XBO 2000 W/DHP L OFR |
| Nominal Wattage | 2000 W |
| Nominal Voltage | 23 V |
| Nominal Current | 87 A |
| Current Control Range | 64–95 A |
| Type of Current | DC |
| Light Center Length (LCL) | 123.0 mm |
| Electrode Gap (cold) | 4.5 mm |
| Base (Anode) | SFaX30-14 |
| Base (Cathode) | SFc30-16 |
| Diameter | 55.0 mm |
| Length | 345.0 mm |
| Length w/ base excl. pins/connection | 295.0 mm |
| Cable/Wire Length (input side) | 130 mm |
| Connector Present | Yes |
| Product Weight | 530 g |
| Burning Position | s15/p15 |
| Cooling | Forced |
| Max Ambient Temp (pinch point) | 230 °C |
| Nominal Lifetime | 3300 hr |
| Warranty Hours | 3300 hrs |
| Service Warranty Lifetime | 3500 hr |
| REACh Primary Article Identifier | 4062172030427 | 4052899275638 |
Compatible Barco Projectors (per provided list)
- Barco DP2K-8S
- Barco DP2K-8Sx
- Barco DP2K-10S
- Barco DP2K-12C
- Barco DP2K-15C
- Barco DP2K-19B
- Barco DP2K-20C
- Barco DP2K-23B
- Barco DP4K-19B
- Barco DP4K-23B
- Barco Digital Cinema 1200
Box Contents
- 1 × OSRAM XBO 2000W/DHP L OFR Xenon Cinema Lamp (68884)
Product Gallery
Please note: Xenon lamps that must be configured or calibrated before shipment cannot be returned.
While we are working to ensure each image we have posted is accurate, there may be items with an incorrect or missing image. Please be sure you are ordering the correct model.
If you have any questions about the 68884 do not hesitate to contact via email at products@jaspertronics.com or by phone at 888-391-5596
